Pad Silicone Selection Guide 4 Models
author: Lulu
2026-09-11
Choosing the right pad printing silicone is important for print quality and cost. Here is a simple guide for 4 models.
Model Comparison
Model Comparison
HY-901 economy grade: 23A hardness, tensile ≥3.0MPa, tear ≥12kN/m. For flat surface general printing, small and medium batch. Most affordable.
HY-902 high wear grade: 28A hardness, tensile ≥4.0MPa, tear ≥18kN/m. For high volume automated lines. Longest pad life 100,000-150,000 prints.
HY-912 multi color grade: 25A hardness, tensile ≥3.5MPa, tear ≥15kN/m. For multi color overprint and fine pattern. Good resilience and overprint accuracy.
HY-916 super soft grade: 16A hardness, tensile ≥2.5MPa, tear ≥10kN/m, elongation ≥400%. For large curvature irregular curved surfaces. Best conformability.
How to Choose
By product shape: flat surface use 901, multi color use 912, complex curved surface use 916.
By production volume: small medium batch use 901, high volume automated use 902.
By budget: limited budget use 901, sufficient budget choose by application.
Simple Mnemonic
901 for flat general, 912 for multi color, 902 for high volume, 916 for curved surface. Free samples available for testing before bulk order.
HY-902 high wear grade: 28A hardness, tensile ≥4.0MPa, tear ≥18kN/m. For high volume automated lines. Longest pad life 100,000-150,000 prints.
HY-912 multi color grade: 25A hardness, tensile ≥3.5MPa, tear ≥15kN/m. For multi color overprint and fine pattern. Good resilience and overprint accuracy.
HY-916 super soft grade: 16A hardness, tensile ≥2.5MPa, tear ≥10kN/m, elongation ≥400%. For large curvature irregular curved surfaces. Best conformability.
How to Choose
By product shape: flat surface use 901, multi color use 912, complex curved surface use 916.
By production volume: small medium batch use 901, high volume automated use 902.
By budget: limited budget use 901, sufficient budget choose by application.
Simple Mnemonic
901 for flat general, 912 for multi color, 902 for high volume, 916 for curved surface. Free samples available for testing before bulk order.
