Fast Cure Thermal Potting Silicone | 2 Hour Cure Electronic Compound for High Power Devices
HY-9055、
HY-9055 is a fast-curing two-component electronic potting silicone with a working time of 15 to 30 minutes and full cure within 2 to 4 hours at 25C. It is designed for high-volume production lines where short cycle times are essential, including 5G power modules, motor controllers and battery management systems.
Quantity
Key Features:
- Two-component addition-cure platinum catalyzed silicone system
- 1:1 mix ratio by weight, easy to meter and dispense
- Excellent electrical insulation above 25 kV/mm
- Wide operating temperature range -60C to 200C
- Self-leveling for complete gap filling with no voids
- UL94 flame retardant rated
- Low shrinkage and low stress on sensitive components
- RoHS and REACH compliant
- Recommended model: HY-9055 - fast cure thermal potting compound for high power modules
Technical Parameters:
Model | Color | Viscosity (mPa.s) | Operation Time (min) | Cure Time (hr) | Thermal Cond. (W/mK) | Flame Rating | Mix Ratio |
HY-9020 | Transparent | 800±200 | 30-60 | 4-8 | ≥0.2 | UL94 V-0 | 1:1 |
HY-9030 | Black | 1500±300 | 20-40 | 3-6 | ≥0.4 | UL94 V-0 | 1:1 |
HY-9040 | Transparent | 600±150 | 40-80 | 6-12 | ≥0.2 | UL94 V-1 | 1:1 |
HY-9050 | White | 2500±500 | 15-30 | 2-4 | ≥0.6 | UL94 V-0 | 1:1 |
HY-9055 | Black/Gray | 2000±400 | 15-30 | 2-4 | ≥0.5 | UL94 V-0 | 1:1 |
Packaging: Standard packaging: 1kg, 5kg, 20kg, 25kg and 200kg kits. A and B components are supplied in separate containers within each kit.
FAQ:
Q: What is the mixing ratio?
A: All HY-9 series potting compounds use a 1:1 mix ratio by weight. We recommend accurate weighing and thorough mixing for 3 to 5 minutes, followed by vacuum degassing for 2 to 3 minutes for best results.
Q: How long does it take to cure?
A: At 25C, HY-9020 cures in 4 to 8 hours, HY-9030 in 3 to 6 hours, HY-9040 in 6 to 12 hours, and HY-9050 and HY-9055 in 2 to 4 hours. Cure time can be shortened significantly by applying mild heat.
Q: Can I get a free sample?
A: Yes, we offer free sample kits up to 1kg for qualified customers. You only cover the shipping cost. Please tell us your application and we will recommend the most suitable grade.
