HY-E628 Silicone for Film & Stage Props

For professionals who refuse to compromise on mold quality, the solution is clear.

Hong Ye Jie's HY-E628 sets the performance standard for addition-cure silicone in film & stage props. At 28A Shore A, it provides toughness and precision.

Core Performance Features

1. Near-Zero Shrinkage (<0.1%)

With linear shrinkage below 0.1%, this material holds tolerances that condensation silicones cannot match.

2. Outstanding Tear Strength (21-26 kN/m)

Thin mold edges, deep undercuts, and intricate details withstand demolding stress without splitting.

3. High Tensile (4.8-6.2 MPa) and Elongation (390-470%)

Structural robustness comes from optimized crosslink density; the material flexes but does not permanently deform.

4. Optimal Viscosity (19000-23000 cps)

Vacuum degassing is enhanced by flow characteristics; bubbles rise and escape efficiently before set.

5. Flexible Working Time (38-75 min at 25 °C)

Working time can be fine-tuned to ambient temperature and project scale.

6. Food-Grade and Skin-Safe Certified

The comprehensive certification package simplifies compliance documentation for regulated markets.

Technical Specifications

Model: HY-E628 Hardness: 28A Shore A Viscosity: 19000-23000 cps Tear Strength: ≥21-26 kN/m Tensile Strength: ≥4.8-6.2 MPa Elongation at Break: ≥390-470% Mixing Ratio: 1:1 or 10:1 (by weight) Pot Life: 38-75 min at 25 °C Curing Time: 4-6 hours at 25 °C Temperature Resistance: -60 to 200 °C Shelf Life: 12 months (sealed) Certifications: ISO 9001, FDA, UL, CE, RoHS, REACH

Application Focus: Film & Stage Props

The HY-E628 is formulated for film & stage props. At 28A Shore A, it balances demolding flexibility with shape retention. Typical projects include theatrical set pieces, movie prop replicas, and animatronic skins.

Practical tips: For on-set rapid prototyping, use heat acceleration at 60 °C. Consider pigmenting silicone for color-matching.

Compatible casting materials:

• polyurethane foam
• epoxy resin
• plaster and gypsum
• latex
• polyester resin

The inert cured silicone does not react with these materials.

Why Choose Hong Ye Jie Technology?

Hong Ye Jie's credentials include 10,000 sqm production space, 20 lines, and 220 tons monthly. Our 60-engineer team provides global support to 20,000+ customers across 138 countries. Trusted by Huawei, BYD, and Delta Electronics.

Get Started

Take advantage of our free sample program. Whether standard or custom-tuned, our R&D team can develop a solution.

Shenzhen Hong Ye Jie Technology Co., Ltd. Tel: +86-755-89948006 Email: info@szrl.net Web: www.szrl.net
