HY-901 Economy Pad Silicone 23A General Purpose
HY-901、
HY-901 is a 23 Shore A economy grade pad printing silicone with tensile ≥3.0MPa and tear ≥12kN/m. Cost effective for flat and slightly curved surface general printing. 100:2 mix, room temp cure in 2-4 hours.
Quantity
HY-901 is a 23 Shore A economy grade pad printing silicone. Tensile ≥3.0MPa, tear ≥12kN/m, elongation ≥300%. 100:2 mix, 30-40 min working time, 2-4 hour cure. General purpose for flat and slightly curved surface printing.
Core Features
Core Features
• 23A economy grade, general purpose
• Tensile ≥3.0MPa, tear ≥12kN/m
• 100:2 mix, 2-4 hour room temp cure
• Uniform ink transfer, clear patterns
• Red/yellow/white/green, custom colors
• Pad life 50,000-80,000 prints
Technical Parameters Table
Model Color Hardness(A) Viscosity Op.Time(min) Cure(h) Tensile(MPa) Tear(kN/m) Elong.(%) Mix Ratio Density
901 R/Y/W/G 23±2 12000 30-40 2-4 ≥3.0 ≥12 ≥300 100:2 1.12
902 R/Y/W/G 28±2 15000 30-40 2-4 ≥4.0 ≥18 ≥320 100:2 1.15
912 R/Y/W/G 25±2 13000 30-45 2-4 ≥3.5 ≥15 ≥350 100:2 1.13
916 R/Y/W/G 16±2 10000 30-40 2-4 ≥2.5 ≥10 ≥400 100:2 1.10
Application Scenarios
Handicraft and advertising gift flat surface logo printing. Economy grade with low cost for small batch multi variety production.
Operation Instructions
Prepare mold, apply release agent
Weigh 100:2 ratio accurately
Stir 3-5 min uniformly
Vacuum degas 5-8 min
Pour into mold slowly
Cure 2-4 hours, demold, rest 24h
Selection Guide
• 901: Economy, flat surface
• 902: High wear, automated lines
• 912: Multi color, overprint
• 916: Super soft, curved surface
Recommended Application
Handicraft and advertising gift flat surface logo printing.
Quality
ISO 9001, COA report, RoHS REACH, stable batch performance.
Packaging
1kg, 5kg, 20kg, 25kg, 200kg drum. Custom labels available.
Advantages
16500 sqm factory, 500 tons/month, cost effective pricing, stock 1-3 days.
Ordering
T/T, PayPal. Free samples. Stock 1-3 days, custom 7-15 days. Not dangerous goods.
Technical Support
10+ years team, custom formulas MOQ 50kg, remote support.
Precautions
Wear gloves, avoid tin/sulfur/amine, weigh accurately, mix uniform, cure 15-35°C, ventilate.
Storage
Cool dry 5-30°C, 12 months shelf life, reseal after use.
FAQ
Q1: When to use HY-901?
A1: For flat or slightly curved surface general printing, small and medium batch. Multi color use 912, high volume use 902, curved use 916.
Q2: Bubbles in pad head?
A2: Insufficient degassing. Vacuum at -0.09MPa for 5+ min until no bubbles.
