HY-901 General Purpose Pad Printing Silicone 30A Cost Effective

HY-901..
HY-901 is a general purpose two component RTV pad printing silicone with 30±2 Shore A hardness. Cost effective and easy to operate. Ideal for making pad heads to print electronic housings, remote controls, toys, stationery and gifts on flat and slightly curved surfaces. Good resilience, uniform ink transfer, long life. ISO 9001 certified.
Quantity
Contact Now
add to cart

HY-901 is a general purpose economical two component RTV pad printing silicone. Made from premium silicone raw materials. Hardness 30±2 Shore A, balanced softness for wide applicability. Tensile strength 3.8MPa, tear strength 22±2kN/m, elongation 380%. Room temperature curing without heating. Simple operation for beginners. ISO 9001 certified with COA for every batch. Monthly production over 100 tons, ready stock.

Core Features • General purpose economical, high cost effectiveness • 30±2 Shore A moderate hardness • 3.8MPa tensile strength, durable • 22±2 kN/m tear strength, abrasion resistant • 380% elongation, good resilience • Room temperature curing, easy operation • 32000±2000 mPa.s viscosity, easy pouring • Uniform ink pickup, clear patterns • No oil bleeding, ink solvent resistant • Ready stock, 3-5 days delivery

Technical Parameters Model: HY-901 | Color: White | Hardness: 30±2 Shore A | Viscosity: 32000±2000 mPa.s | Operation Time: 30-40 min | Cure Time: 3-4 h | Tensile Strength: 3.8 MPa | Tear Strength: 22±2 kN/m | Elongation: 380% | Mix Ratio: 100:2~100:3 | Density: 1.12±0.03 g/cm3 Model: HY-902 | Color: White | Hardness: 30±2 Shore A | Viscosity: 35000±2000 mPa.s | Operation Time: 30-40 min | Cure Time: 3-4 h | Tensile Strength: 4.0 MPa | Tear Strength: 24±2 kN/m | Elongation: 430% | Mix Ratio: 100:2~100:3 | Density: 1.15±0.03 g/cm3 Model: HY-912 | Color: White | Hardness: 30±2 Shore A | Viscosity: 32000±2000 mPa.s | Operation Time: 30-40 min | Cure Time: 3-4 h | Tensile Strength: 4.0 MPa | Tear Strength: 25±2 kN/m | Elongation: 340% | Mix Ratio: 100:2~100:3 | Density: 1.13±0.03 g/cm3 Model: HY-916 | Color: White | Hardness: 14±2 Shore A | Viscosity: 36000±2000 mPa.s | Operation Time: 30-40 min | Cure Time: 3-4 h | Tensile Strength: 3.5 MPa | Tear Strength: 25±2 kN/m | Elongation: 570% | Mix Ratio: 100:2~100:3 | Density: 1.10±0.03 g/cm3

Application Scenarios Electronic housings: Remote controls, control panels, chargers, mice, keyboards. Flat or slightly curved surfaces. HY-901 30A pad heads provide sharp pattern edges and good conformity. 30% lower pad head replacement frequency. Toys and stationery: Plastic toys, educational toys, pens, rulers. Large batch, diverse shapes, high safety. HY-901 cost effective for high volume production. RoHS and REACH compliant, no heavy metals.

Operation Instructions

  1. Prepare scale, stirring rod, mold, gloves. Clean environment 20-30C.
  2. Weigh Component A accurately.
  3. Add Component B at 100:2 to 100:3 ratio.
  4. Stir 3-5 minutes thoroughly.
  5. Degas 3-5 minutes.
  6. Pour into mold, cure 3-4 hours at room temperature. Rest 24 hours before use.

Selection Guide HY-901: 30A general purpose, most economical, for flat and simple curves, beginners. HY-902: 30A high abrasion, longer life, for high volume continuous production. HY-912: 30A multi color, good overprint accuracy, for multi color printing. HY-916: 14A ultra soft, 570% elongation, for complex curved surfaces.

Recommended Application Best for electronic housings, remote controls, toys, stationery on flat and slightly curved surfaces.

Quality and Compliance ISO 9001 certified. Every batch tested with COA. RoHS and REACH compliant. 20+ years brand history, 50+ countries.

Packaging A: 20kg/25kg bucket, 200kg drum. B: 1kg bottle. 1kg trial and 5kg small pack available. OEM available.

Competitive Advantages Self owned factory, 100+ tons monthly. 30-50% lower than imported. 3-5 days delivery. Free technical support. Custom hardness and color. OEM available.

Ordering and Logistics T/T or PayPal. Stock ships 3-5 days. Sea, air or express. Not dangerous goods. COA and MSDS included.

Technical Support Experienced engineers, full lifecycle support. Custom formulations (hardness 10A-50A, color, cure time). MOQ 50kg, 7-10 days lead time.

Precautions Wear nitrile gloves. Avoid nitrogen, sulfur, tin, phosphorus substances. Weigh accurately. Mix thoroughly. Cure below 50C. Ventilate.

Storage Store 5-30C cool dry place. 12 months shelf life unopened. Reseal after use. Refrigerate 2-8C to extend.

FAQ Q: How many prints per pad head? A: 50,000-80,000 prints under normal conditions.

Q: HY-901 vs HY-902? A: Both 30A. HY-901 economical for regular production. HY-902 higher abrasion, longer life for high volume.

Q: Incomplete cure? A: Check ratio, mixing, temperature above 20C, no inhibiting substances.
