HY-902 30A High Wear Pad Printing Silicone 150K Prints Life
HY-902+-
HY-902 is 30 Shore A high wear pad printing silicone with tensile 4.0MPa, tear 24kN/m, elongation 430%, pad head life 100K to 150K prints, viscosity 35000mPa.s, 30-40 min working time, 3-4 hour cure, excellent ink solvent resistance, for high volume automated cosmetic and craft printing.
Quantity
HY-902 is high wear resistant pad printing silicone for high volume high frequency automated pad printing lines. 30 Shore A, tensile 4.0MPa, tear 24kN/m, elongation 430%. Pad head life 100K to 150K prints, much longer than economy grade. Slightly higher unit price but lower comprehensive usage cost. Stable ink transfer, excellent solvent resistance, linear shrinkage ≤0.3%. 100:2 to 100:3 mix, 30-40 min working, 3-4 hour cure. Widely used in cosmetic packaging, crafts gifts, electronics.
Core Features
• 30A high wear, pad head life 100K to 150K prints
• Tensile 4.0MPa, tear 24kN/m, elongation 430%
• Excellent ink solvent resistance
• Stable ink transfer, clear patterns
• Linear shrinkage ≤0.3%, dimensional stability
• 100:2 to 100:3 mix, simple operation
• 30-40 min working, 3-4 hour cure
• Lower comprehensive usage cost
Technical Parameters
Model Color Hardness(A) Viscosity(mPa.s) Op Time(min) Cure(h) Tensile(MPa) Tear(kN/m) Elongation(%) Mix Ratio Density(g/cm3)
HY-902 White 30±2 35000±2000 30-40 3-4 4.0 24±2 430 100:2~100:3 1.15±0.03
HY-901 White 30±2 32000±2000 30-40 3-4 3.8 22±2 380 100:2~100:3 1.12±0.03
HY-912 White 30±2 32000±2000 30-40 3-4 4.0 25±2 340 100:2~100:3 1.13±0.03
HY-916 White 14±2 36000±2000 30-40 3-4 3.5 25±2 570 100:2~100:3 1.10±0.03
Application Scenarios
Cosmetic packaging: perfume bottles, lotion bottles, cream jars, lipstick tubes, high volume logo printing. Long pad head life reduces replacement, lower comprehensive cost.
Crafts gifts: ceramic, resin, glass, metal crafts, keychains, holiday gifts. Stable printing, dimensional consistency for medium large batch orders.
Operation Instructions
Clean mold, apply release agent, dry 10 min
Weigh 100:2 to 100:3 accurately
Stir 3-5 min, scrape bottom and walls
Vacuum degas -0.09MPa, 5-8 min
Pour slowly along mold wall
Room temp cure 3-4 hours, demold, rest 24h
Selection Guide
• HY-901: economy, small medium batch
• HY-902: high wear, long life, high volume automated
• HY-912: multi color, overprint accuracy
• HY-916: super soft, complex curved surface
Recommended Application
Cosmetic packaging and crafts gifts high volume automated printing.
Quality and Compliance
ISO 9001 certified, COA per batch, RoHS REACH compliant, SGS tested.
Packaging
1kg, 5kg, 20kg, 25kg, 200kg drum. A and B separately packed.
Competitive Advantages
16,500 sqm factory, 500 tons monthly, cost 30-50% lower than imports, stock 1-3 days.
Ordering and Logistics
T/T PayPal, free samples freight collect, stock 1-3 days, sea air express, not dangerous goods.
Technical Support
10+ year experience team, full lifecycle support, custom formula MOQ 50kg.
Precautions
Wear nitrile gloves, avoid tin sulfur amine, weigh accurately, mix uniformly, cure 15-35°C, ventilate.
Storage
Cool dry 5-30°C, shelf life 12 months, reseal after use, refrigeration extends life.
FAQ
Q1: HY-902 vs HY-901? A1: HY-902 high wear, life 100-150K prints, for high volume; HY-901 economy, 50-80K prints, for small medium batch.
Q2: How to extend pad head life? A2: moderate pressure, regular cleaning, cool dry storage, avoid sharp objects, select right model.
