Professional Medical Devices Mold Silicone HY-E635 - 35A Near-Zero Shrinkage

Engineered for Medical Devices, HY-E635 combines 35A Shore A hardness with balanced flow. Platinum catalyst ensures clean, predictable curing with no toxic byproducts.

Core Performance Features

• 1. Near-Zero Shrinkage (<0.1%) — Parts require zero rework for fit.
• 2. Outstanding Tear Strength (23-29 kN/m) — Molds withstand long production runs.
• 3. High Tensile (5.2-6.8 MPa) and Elongation (380-440%) — Stretches over undercuts and returns without deformation.
• 4. Optimal Viscosity (22000-26000 cps) — Balances detail capture with body.
• 5. Flexible Working Time (32-65 min at 25°C) — Ample time for multi-piece assemblies.
• 6. Food-Grade & Skin-Safe — Low VOC, no harsh fumes, FDA certified.

Technical Specifications

Model: HY-E635 | Hardness: 35A | Viscosity: 22000-26000 cps

Tear: ≥23-29 kN/m | Tensile: ≥5.2-6.8 MPa | Elongation: ≥380-440%

Ratio: 1:1 or 10:1 | Pot Life: 32-65 min | Cure: 4-6h at 25°C

Temp: -60 to 200°C | Shelf: 12 months

Certifications: ISO 9001, FDA, UL, CE, RoHS, REACH

Application Focus

HY-E635 suits prosthetic component molds and surgical training models. Chemically inert with medical-grade epoxy and dental acrylics. Validate biocompatibility per ISO 10993 before medical use. Compatible with medical-grade epoxy, biocompatible polyurethanes, dental acrylics, wax, and FDA-compliant resins.

Why Hong Ye Jie?

25+ years in platinum-cure silicone. 10,000 sqm factory, 20 lines, 220-ton monthly capacity. 60 engineers serving customers in 138 countries. Quality validated by Huawei, BYD, and First Solar.

Shenzhen Hong Ye Jie Technology Co., Ltd.
